Model Details

S-MU-VDGR-64-REACH

Printer Friendly
S-MU-VDGR-64-REACH

Steel Vertical Drum Gripper/Rotator Stacker With Gripper Max Reach 35.5 In. Dispensing Height 71 In. 800 Lb. Capacity Black / Yellow

The fully powered vertical drum gripper/rotator is a great asset for the manufacturing and distributing industries. The shortened length allows for use in very tight areas, while the extendable reach helps load and unload places where access is limited, such as pallets and skids. A walk behind design with a max unloaded speed of over 3 mph and a single handle control makes maneuvering into the desired position easy, maximizing efficiency. Long term battery charge allows for constant daily use without needless downtime.

  • 800 lb. lifting capacity
  • Compatible with 16, 20, 30 & 55 gallon drums
  • Battery charger and level gauge included
  • 35.5" maximum reach
Total Ship Wt.(lbs.): 1731 (only 1 package) Size: 39"W x 94"L x 79.75"H Color: Blaack | Yellow Non-Returnable

Uniform Capacity (lb.): 800 Lowered Height (in.): 15-1/4 Raised Height (in.): 71
Drum Type: 16, 20, 30 & 55 gallon steel Drum Dispense Height (in.): 71 Battery Quantity/Voltage: (2) 12V
Travel Speed unload/load (mph): 3.43/2.8 Maximum Reach (in.): 35-1/2 Front Roller Caster Quantity: 2
Front Roller Caster Diameter x Width (in.): 6 x 2 Driver Caster Quantity: 2 Driver Caster Diameter x Width (in.): 10 x 3-1/8
Caster Material: Poly on Steel Caster Color: Yellow Handle Height (in.): 50
Handle Diameter (in.): 1-1/8 Overall Length (in.): 94 Overall Width (in.): 39
Overall Height (in.)79-3/4:

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

Details For Model: S-MU-VDGR-64-REACH
S-MU-VDGR-64-REACH

Steel Vertical Drum Gripper/Rotator Stacker With Gripper Max Reach 35.5 In. Dispensing Height 71 In. 800 Lb. Capacity Black / Yellow

The fully powered vertical drum gripper/rotator is a great asset for the manufacturing and distributing industries. The shortened length allows for use in very tight areas, while the extendable reach helps load and unload places where access is limited, such as pallets and skids. A walk behind design with a max unloaded speed of over 3 mph and a single handle control makes maneuvering into the desired position easy, maximizing efficiency. Long term battery charge allows for constant daily use without needless downtime.

  • 800 lb. lifting capacity
  • Compatible with 16, 20, 30 & 55 gallon drums
  • Battery charger and level gauge included
  • 35.5" maximum reach
Dimensions: 39"W x 94"L x 79.75"H Sell UOM: EA-Each Color: Blaack | Yellow
Material: Steel UPC: 691215378642 GTIN: 00691215378642
Warranty: -- Shipping Weight: 1731 Quickship Item? --
Can It Ship UPS? -- Option? N Origin: China
Assembly: Assembled Packaging: BASE_UNIT_OR_EACH Drawing Required? Y
Uniform Capacity (lb.): 800 Lowered Height (in.): 15-1/4 Raised Height (in.): 71
Drum Type: 16, 20, 30 & 55 gallon steel Drum Dispense Height (in.): 71 Battery Quantity/Voltage: (2) 12V
Travel Speed unload/load (mph): 3.43/2.8 Maximum Reach (in.): 35-1/2 Front Roller Caster Quantity: 2
Front Roller Caster Diameter x Width (in.): 6 x 2 Driver Caster Quantity: 2 Driver Caster Diameter x Width (in.): 10 x 3-1/8
Caster Material: Poly on Steel Caster Color: Yellow Handle Height (in.): 50
Handle Diameter (in.): 1-1/8 Overall Length (in.): 94 Overall Width (in.): 39
Overall Height (in.)79-3/4:
