Highway Guard Rail Systems

model: GR

GR_X.jpg GR-H2R-DI-8-YL_C.jpg GR-H2R-DI-8-YL_B.jpg GR-H2R-DI-8-HDG_D.jpg GR-H2R-DI-8-YL_D.jpg GR-H2R-DI-4-YL_B.jpg GR-H2R-DI-12-HDG_D.jpg GR-H2R-DI-10-YL_B.jpg More Images +
Highway Guard Rail Systems
SERIES: GR-H2R

Protect personnel and equipment both visually and physically with our Guard Rail Systems. These economical systems can be utilized indoors or outdoors. Ideal for protecting corners of buildings and machinery from fork truck and vehicle damage. Choose between one, two, or three high rail systems. Tubular posts are machined for continuous or perpendicular rail mounting. GR series has rail slotted mounting holes 3/4" x 2-1/2" provided. Rail mounting hardware is included with posts. Floor mounting hardware is sold separately. Deduct 5" when overlapping on a shared post. Units are rated for 4,000 lbs. at 4 mph.

Model # Guide
Guard Rail old Model # to new Model # Conversion Guide

Posts, End Caps, Brackets & Floor Mounting Hardware Can Be Found Below Under Options

Highway Guard Rail Systems

model: GR

Table Search, not an entire site search.
Model # Description Attributes Net Wt.
(lbs)
GR-H2R-BO-10-HDG GR-H2R-BO-10-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 120 In. Length GrayMounting Posts Required (qty.): 3
Rail Style: Straight		104
GR-H2R-BO-10-YL GR-H2R-BO-10-YL90 Days Limited WarrantySteel Straight Guard Rail 120 In. Length YellowMounting Posts Required (qty.): 3
Rail Style: Straight		104
GR-H2R-BO-11-HDG GR-H2R-BO-11-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 132 In. Length GrayMounting Posts Required (qty.): 3
Rail Style: Straight		112
GR-H2R-BO-11-YL GR-H2R-BO-11-YL90 Days Limited WarrantySteel Straight Guard Rail 132 In. Length YellowMounting Posts Required (qty.): 3
Rail Style Curved (degrees): 90		112
GR-H2R-BO-12-HDG GR-H2R-BO-12-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 144 In. Length GrayMounting Posts Required (qty.): 3
Rail Style: Straight		120
GR-H2R-BO-12-YL GR-H2R-BO-12-YL90 Days Limited WarrantySteel Straight Guard Rail 144 In. Length YellowMounting Posts Required (qty.): 3
Rail Style: Straight		120
GR-H2R-BO-3-HDG GR-H2R-BO-3-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 36 In Length GrayMounting Posts Required (qty.): 2
Rail Style: Straight		20
GR-H2R-BO-3-YL GR-H2R-BO-3-YL90 Days Limited WarrantySteel Straight Guard Rail 36 In Length YellowMounting Posts Required (qty.): 2
Rail Style: Straight		20
GR-H2R-BO-4-HDG GR-H2R-BO-4-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 48 In. Length GrayMounting Posts Required (qty.): 2
Rail Style: Straight		30
GR-H2R-BO-4-YL GR-H2R-BO-4-YL90 Days Limited WarrantySteel Straight Guard Rail 48 In. Length YellowMounting Posts Required (qty.): 2
Rail Style: Straight		30
GR-H2R-BO-5-HDG GR-H2R-BO-5-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 60 In. Length GrayMounting Posts Required (qty.): 2
Rail Style: Straight		41
GR-H2R-BO-5-YL GR-H2R-BO-5-YL90 Days Limited WarrantySteel Straight Guard Rail 60 In. Length YellowMounting Posts Required (qty.): 2
Rail Style: Straight		41
GR-H2R-BO-6-HDG GR-H2R-BO-6-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 72 In. Length GrayMounting Posts Required (qty.): 2
Rail Style: Straight		48
GR-H2R-BO-6-YL GR-H2R-BO-6-YL90 Days Limited WarrantySteel Straight Guard Rail 72 In. Length YellowMounting Posts Required (qty.): 2
Rail Style: Straight		48
GR-H2R-BO-7-HDG GR-H2R-BO-7-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 84 In. Length GrayMounting Posts Required (qty.): 2
Rail Style: Straight		76
GR-H2R-BO-7-YL GR-H2R-BO-7-YL90 Days Limited WarrantySteel Straight Guard Rail 84 In. Length YellowMounting Posts Required (qty.): 2
Rail Style: Straight		76
GR-H2R-BO-8-HDG POPULAR GR-H2R-BO-8-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 96 In. Length GrayMounting Posts Required (qty.): 2
Rail Style: Straight		78
GR-H2R-BO-8-YL GR-H2R-BO-8-YL90 Days Limited WarrantySteel Straight Guard Rail 96 In. Length YellowMounting Posts Required (qty.): 2
Rail Style: Straight		78
GR-H2R-BO-9-HDG GR-H2R-BO-9-HDG90 Days Limited WarrantyGalvanized Steel Straight Guard Rail 108 In. Length GrayMounting Posts Required (qty.): 3
Rail Style: Straight		86
GR-H2R-BO-9-YL GR-H2R-BO-9-YL90 Days Limited WarrantySteel Straight Guard Rail 108 In. Length YellowMounting Posts Required (qty.): 3
Rail Style: Straight		86
GR-H2R-CRV-BO-10-HDG GR-H2R-CRV-BO-10-HDG90 Days Limited WarrantyGalvanized Steel Curved Guard Rail 120 In. Length GrayMounting Posts Required (qty.): 3
Rail Style Curved (degrees): 90		85
GR-H2R-CRV-BO-12-HDG GR-H2R-CRV-BO-12-HDG90 Days Limited WarrantyGalvanized Steel Curved Guard Rail 144 In. Length GrayMounting Posts Required (qty.): 3
Rail Style Curved (degrees): 90		135
GR-H2R-CRV-BO-4-HDG GR-H2R-CRV-BO-4-HDG90 Days Limited WarrantyGalvanized Steel Curved Guard Rail 48 In. Length GrayMounting Posts Required (qty.): 2
Rail Style Curved (degrees): 90		32
GR-H2R-CRV-BO-6-HDG GR-H2R-CRV-BO-6-HDG90 Days Limited WarrantyGalvanized Steel Curved Guard Rail 72 In. Length GrayMounting Posts Required (qty.): 2
Rail Style Curved (degrees): 90		55
GR-H2R-CRV-BO-8-HDG GR-H2R-CRV-BO-8-HDG90 Days Limited WarrantyGalvanized Steel Curved Guard Rail 96 In. Length GrayMounting Posts Required (qty.): 2
Rail Style Curved (degrees): 90		69
GR-H2R-DI-10-HDG GR-H2R-DI-10-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 120 In. Length GrayMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		82
GR-H2R-DI-10-YL GR-H2R-DI-10-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 120 In. Length YellowMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		82
GR-H2R-DI-11-HDG GR-H2R-DI-11-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 132 In. Length GrayMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		88
GR-H2R-DI-11-YL GR-H2R-DI-11-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 132 In. Length YellowMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		88
GR-H2R-DI-12-HDG GR-H2R-DI-12-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 144 In. Length GrayMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		95
GR-H2R-DI-12-YL GR-H2R-DI-12-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 144 In. Length YellowMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		95
GR-H2R-DI-3-HDG GR-H2R-DI-3-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 36 In Length GrayMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		34
GR-H2R-DI-3-YL GR-H2R-DI-3-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 36 In Length YellowMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		34
GR-H2R-DI-4-HDG GR-H2R-DI-4-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 48 In. Length GrayMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		41
GR-H2R-DI-4-YL GR-H2R-DI-4-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 48 In. Length YellowMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		41
GR-H2R-DI-5-HDG GR-H2R-DI-5-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 60 In. Length GrayMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		48
GR-H2R-DI-5-YL GR-H2R-DI-5-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 60 In. Length YellowMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		48
GR-H2R-DI-6-HDG GR-H2R-DI-6-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 72 In. Length GrayMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		55
GR-H2R-DI-6-YL GR-H2R-DI-6-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 72 In. Length YellowMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		55
GR-H2R-DI-7-HDG GR-H2R-DI-7-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 84 In. Length GrayMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		61
GR-H2R-DI-7-YL GR-H2R-DI-7-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 84 In. Length YellowMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		61
GR-H2R-DI-8-HDG GR-H2R-DI-8-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 96 In. Length GrayMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		68
GR-H2R-DI-8-YL GR-H2R-DI-8-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 96 In. Length YellowMounting Posts Required (qty.): 2
Brackets and Hardware Included (qty.): 2		68
GR-H2R-DI-9-HDG GR-H2R-DI-9-HDG90 Days Limited WarrantyGalvanized Steel Drop In Guard Rail 2 Ribbed 108 In. Length GrayMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		75
GR-H2R-DI-9-YL GR-H2R-DI-9-YL90 Days Limited WarrantySteel Drop In Guard Rail 2 Ribbed 108 In. Length YellowMounting Posts Required (qty.): 3
Brackets and Hardware Included (qty.): 3		75

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.

KEY: = Expand Model Details = Quickship item = Non-Returnable item = Approval Drawing Required = Non-Cancelable Item
= On Hold/Temporarily Unavailable = Approval Drawing = Testing Certificate = BABAA Compliant = 360 Image Warranty
= Works w/ Skid Only = Flatbed Truck Required

If you did not find an expected Model or SKU # in the table, try the Options Section Below
